Specifications:
- Windows Vista Home Premium (SP1, 32-bit)
- Intel Core 2 Duo processor P8600 (2.4GHz, 3MB L2 Cache, 1066MHz FSB)
- 15.6" High Definition (1920x1080) High Brightness LED Display with TrueLife and Camera
- 3GB DDR2 SDRAM 800MHz System Memory
- ATI Mobility Radeon HD 4570 graphics (256MB)
- 250GB 7200RPM SATA Hard Drive
- 6X Slot Load Blu-ray (BD) Combo Drive (BD Read Only)
- Dell Wireless 1397 802.11g Half Mini-Card
- Dell Wireless 370 Bluetooth Internal (2.1)
- Weight: 5.8 lb. including 9-cell battery
- Dimensions: 1.0-2.0 x 14.6 x 10.0 inches with 9-cell battery (H x W x D)
- Battery: 9-cell 85Wh
- Dell Design Studio Custom Lid: XenoMayan - Haab3 by Tweeqim
- Warranty: 1 year system
- Retail Price as configured: $1,299
Build and Design
Im sure some of our readers will be a little confused by this review and wonder, "Didnt NotebookReview.com already review the Studio 15?" The answer is yes and no ... just to confuse you even more. Dell decided that the original Studio 15 (model 1535) needed some improvements, and when LCD manufacturers stopped making 16:10 ratio LCDs and switched to 16:9 ratio screens it gave Dell the perfect opportunity to launch a new Studio 15 (1555).
With that being said, the changes between the original Studio 15 (1535) and the new Studio 15 (1555) are fairly minor. Dell obviously increased the width of the notebook in order to accommodate the wider 15.6" LCD with its 16:9 aspect ratio. The new Studio 15 also features a black screen bezel compared to the silver bezel on the old Studio 15. The only other obvious changes are the removal of dedicated media buttons and changes to the port layout. Well talk more on those changes later in the review.
Overall, The Studio 15 is still an impressive looking desktop replacement. I use the term "desktop replacement" because most people in the market for a 15-inch notebook arent planning to haul their notebook everywhere during frequent airline travel.
While the Studio 15 isnt exactly a thin-and-light notebook designed for mobility, its still a very portable multimedia entertainment notebook. The Studio 1555 takes several design elements from the earlier Studio 1535: the wedge-shaped profile, drop hinge, and slot-loading optical drive.
The Studio 15 is available in your choice of six colors: Plum Purple, Promise Pink, Midnight Blue, Ruby Red, Spring Green or standard Black Chainlink. If those arent enough options for you, the Dell Design Studio offers the Studio 15 in your choice of more than 200 different designs by various artists. We selected the "XenoMayan" lid design and also went one step further and selected the "Haab3" variation of the design by the Tweeqim artist studio.
When closed the Studio 15 doesnt feel as sturdy as you might expect. The screen lid shows significant flex under very light pressure. Considering the added cost of the fancy lid I dont think its too much to expect some reinforcement so that the lid feels firm when you hold it. Likewise, the bottom of the chassis shows quite a bit of flex near the center of the notebook. Long story short: The Studio 15 does not feel particularly rugged. I suspect the plastics used will withstand regular day-to-day abuse inside a backpack or on a desk without showing too much wear and tear, but the laptop just doesnt "feel" solid.
The bottom of the notebook features the battery and a single access plate that must be removed in order to upgrade the RAM, hard drive, or replace any additional components. On the bright side, Dell improved the access panel on the Studio 1555 so that you only have to remove three screws to upgrade the RAM or the hard drive. Unfortunately, as previously mentioned, the bottom of the notebook doesnt feel particularly sturdy.
Screen and Speakers
The 15.6-inch high definition (1920x1080) panel on the Studio 15 rates fairly average with vibrant colors and excellent contrast. The display panel in our review unit appears to be an LG model (LGD020B). The LED backlighting in our review unit is nice and bright, but we did notice that the brightness was slightly uneven in the upper right corner of the screen. Yes, it is a 16:9 screen ratio, but this is starting to become standard for all notebooks and isnt really a problem when youve got a higher resolution panel like this one. Horizontal viewing angles are extremely good, so you wont have any trouble sharing a movie with a friend or two. Upper vertical viewing angles are above average since the colors dont wash out too much when viewed from above but colors begin to distort and invert as you move the screen back.
Im at a loss when it comes to describing the stereo speakers on the Studio 15. The nicest thing I can honestly say about these speakers is they produce sound. The frequency range of these speakers is downright horrible. High frequencies sound weak and distorted, and bass is completely absent. Also, because of the weakness of the speakers and their close proximity to one another, they sound more like a mono speaker than stereo speakers. The best way I can describe the audio coming out of the built-in speakers is to tell you that during our lab tests when we played several songs to test the speaker performance one of our editors down the hall thought we were running an electric sander because of the flat, high-pitched noise coming from the lab.
The Studio 15 (1555) does have a built-in subwoofer, but the subwoofer output was either extremely weak or non-existent in our review unit. Id like to hope this is just an issue with our review unit, but thats not clear.
External speakers or headphones are a must-have accessory with this laptop.
Keyboard and Touchpad
The backlit keyboard on our review unit of the Studio 15 is very nice and similar to the one on the original Studio 15. The keyboard is quite comfortable to type on with reasonable key size and spacing. There is some obvious flex when typing pressure is applied around the "L" key, but the left side of the keyboard is reasonably firm. If Dell put some additional reinforcement under the right side of the keyboard then this would be a nearly perfect keyboard.
The biggest difference between the keyboard on the Studio 1535 and the new Studio 1555 is that the new keyboard lacks dedicated media buttons. Instead, the new keyboard moves the media controls to the F-keys on the top row of the keyboard. On one hand I really like this change because of gives you physical controls for several different functions. On the other hand, if you frequently use the F-keys for things like refreshing your web browser you now have to press the Fn key as well.
The Synaptics-based touchpad is large and comfortable to use with a nice texture. Sensitivity is good, accurately tracking finger movement with little pressure on the surface. The multi-touch gestures (such as zoom in and zoom out) are easy to use. The only thing I didnt like about the touchpad is that Dell uses their own touchpad drivers rather than the standard Synaptics drivers ... making it more difficult to adjust settings. The touchpad buttons themselves have excellent feedback with a deep throw and well-cushioned press.
Ports and Features
The port selection on the Studio 1555 is nice, but surprisingly not as good as the original Studio 15 (1535). The new Studio 15 has one fewer USB ports and only has an ExpressCard/34 slot rather than an ExpressCard/54 slot. Granted, many 15-inch notebooks only have three USB ports, but now that most 10-inch netbooks have three USB ports it seems odd when a 15-inch notebook doesnt have at least four. Still, the inclusion of eSATA, FireWire and HDMI for connecting your laptop to a larger HDTV or external monitor are welcome features to have on a multimedia notebook.
Front: No ports or Indicator lights.
Rear: Screen hinges, battery, and heat vent.
Left: Kensington lock slot, HDMI, VGA, Ethernet, USB/eSATA combo port, USB port, FireWire, microphone jack and two headphone jacks.
Right: ExpressCard/34, media card reader, Slot-loading optical drive, USB, and power jack
Performance
The performance of the Studio 15 with an Intel Core 2 Duo P8600 processor and ATI Radeon 4570 discrete graphics iss exceptionally good. This is the level of performance we like to see from multimedia oriented notebooks with discrete graphics. Whether youre watching a Blu-ray movie, playing a few levels of Left 4 Dead, or streaming video via YouTube HD this notebook has the power to get the job done.
We would have loved to see even more discrete graphics options available on the Dell website, but the ATI Radeon options should provide more than enough performance for average consumers looking to purchase this laptop for multimedia use around the home.
wPrime processor comparison results (lower scores mean better performance):
Dell Studio 15 (1555) (Core 2 Duo P8600 @ 2.4GHz)
| 32.995 seconds |
Toshiba Satellite A355 (Core 2 Duo P7450 @ 2.16GHz)
| 35.848 seconds |
Lenovo IdeaPad Y530 (Core 2 Duo P7350 @ 2.0GHz) | 38.455 seconds |
Lenovo G530 (Intel Pentium Dual-Core T3400 @ 2.16GHz)
| 38.470 seconds |
HP Pavilion dv5z (Turion X2 Ultra ZM-80 @ 2.1GHz)
| 39.745 seconds |
Dell Studio 15 (1535) (Core 2 Duo T5750 @ 2.0GHz) | 41.246 seconds |
PCMark05 measures overall system performance (higher scores mean better performance):
Toshiba Satellite A355 (2.16GHz Intel P7450, ATI Radeon HD 3650 512MB) | 5,842 PCMarks |
Dell Studio 15 (1555) (2.4GHz Intel P8600, ATI Radeon HD 4570 256MB) | 5,731 PCMarks |
Lenovo IdeaPad Y530 (2.0GHz Intel P7350, Nvidia 9300M 256MB)
| 4,844 PCMarks |
Lenovo G530 (2.16GHz Intel Pentium Dual-Core T3400, Intel Intel 4500MHD) | 4,110 PCMarks |
Dell Studio 15 (1535) (2.0GHz Intel T5750, Intel X3100) | 3,998 PCMarks |
HP Pavilion dv5z (2.1GHz Turion X2 Ultra ZM-80, ATI Radeon HD 3200) | 3,994 PCMarks |
3DMark06 measures video and gaming performance (higher scores mean better performance):
Dell Studio 15 (1555) (2.4GHz Intel P8600, ATI Radeon HD 4570 256MB) | 4,189 3DMarks |
Toshiba Satellite A355 (2.16GHz Intel P7450, ATI Radeon HD 3650 512MB) | 4,084 3DMarks |
Lenovo IdeaPad Y530 (2.0GHz Intel P7350, Nvidia 9300M 256MB) | 1,833 3DMarks |
HP Pavilion dv5z (2.1GHz Turion X2 Ultra ZM-80, ATI Radeon HD 3200) | 1,599 3DMarks |
Lenovo G530 (2.16GHz Intel Pentium Dual-Core T3400, Intel Intel 4500MHD)
| 730 3DMarks |
Dell Studio 15 (1535) (2.0GHz Intel T5750, Intel X3100) | 493 3DMarks |
All of the 3DMark06 scores for all of the systems listed above were run at 1280 x 800 resolution. However, due to the 16:9 screen ratio on the Studio 15 (1555) we benchmarked the notebook at 1280x768 ... which was the closest resolution available in 3DMark06 for use with the built-in screen.
For those who are interested, the 3DMark06 score at the native resolution of 1920x1080 is 2,985 3DMarks ... still impressive for average multimedia use and gaming.
HDTune storage drive performance results:
Battery
With the screen brightness set to 70%, wireless active, and the Vista power profile set to "Balanced" the Studio 15 stayed on for 3 hours and 42 minutes of constant use. To be honest, discrete graphics and 1080p displays usually result in less-than-spectacular battery life, but we were hoping to see more from this notebook with the 9-cell 85Wh extended life battery. Bottom line, this is perfectly fine for a desktop replacement or for average use around the house, but if you need a notebook to be your constant travel companion then the Studio 15 might not be the best choice.
Heat and Noise
The cooling system does an acceptable job keeping temperatures under control. The area around the hard drive, RAM, and wireless cards produced the most obvious heat on the external surfaces of the notebook, but temperatures werent hot enough to prevent me from using the Studio 15 as a "laptop." The temperature readings below (listed in degrees Fahrenheit) were taken after stressing the system with performance benchmarks for 30 minutes and should reflect typical external temperatures after more than an hour of serious use.
| |
Noise wasnt much of an issue with the Studio 15. The slot-loading optical drive made some noise when inserting or ejecting a disk but it was average for the slot-loading drives weve had in our office. The cooling fan is loud enough to be noticed in a quiet room, but shouldnt be an issue unless you must have absolute silence.
The hard drive was likewise quiet and it seems as if Dell has done a good job finding ways to minimize the noise coming from the hard drive. We did notice some sporadic CPU/southbridge whine coming from our review unit, but it was extremely high-frequency noise and might not be common to all Studio 15 models.
Conclusion
The Dell Studio 15 (1555) offers an impressive balance of customizable features and performance at a fair price. The modern looks, custom lid options, and affordable upgrades are sure to make this a popular notebook for many consumers. Unfortunately, the weak speakers, lackluster build quality, and average port selection will probably leave several owners wanting more.
If youre in the market for a nice family PC that has a fantastic range of multimedia features at a good price then the Dell Studio 15 is worth consideration. If you cant look beyond the flexible plastics and horrible speakers then luckily there are many alternatives on the market with 15-inch screens.
Pros:
- Great customizable options
- Good value and performance
- Cool Dell Design Studio lids
Cons:
- Pathetic speakers
- Could use more USB ports
- Average build quality
